Customized hole stainless steel through floating valve ball

Customized hole stainless steel through floating valve ball

Customized hole stainless steel through floating valve ball

Product detail:


Stainless Steel Floating Valve Ball

Material

Stainless Steel

Specifications

DN50

Scope of application

Floating Valve Ball

Pressure range

1.0Mpa~2.5Mpa

Connection

Customize by customers request

Standard

JB/T2203-1999

Type

Straight-through type

Sample

7-10 days to make by drawings

Packing

Bag,inner box,carton packing in pallet

Delivery time

25-30 days after confirm the order

OEM

We can produce by customer drawings

Inspect

The products was inspected before shipment



Option Material List
  201 F304 F316
%C 0.15MAX 0.08MAX 0.07MAX
%Si 1.00MAX 1.00MAX 1.00MAX
%Mn 5.50-7.50 2.00MAX 2.00MAX
%P 0.06MAX 0.045MAX 0.045MAX
%S 0.03MAX 0.03MAX 0.03MAX
%Cr 16.00-18.00 18.00-20.00 16.50-18.00
%Ni 3.50-5.50 8.00-11.00 10.00-14.00
%N 0.25MAX   0.10MAX
%Mo     2.00-3.00
  F6AISI410 NO6625 F51
%C 0.08-0.15 0.10MAX 0.03MAX
%Si 1.00MAX 0.50MAX 1.00MAX
%Mn 1.00MAX 0.50MAX 2.00MAX
%P 0.04MAX 0.015MAX 0.03MAX
%S 0.03MAX 0.015MAX 0.02MAX
%Cr 11.50-13.50 20.00-23.00 21.00-23.00
%Ni   58.00MIN
%N     0.08-0.20
%Mo   8.00-10.00 2.50-3.50


Option Valve Ball Specification
Floating Valve Ball Option Size:NPS 2-12(DN50-300)
Trunnion Valve Ball Option Size:NPS2-24(DN50-600)
Hollow Valve Ball Option Size:NPS 2-12(DN50-300)
Hard Seal Valve Ball Option Size:NPS2-18(DN50-600)
Stem Valve Ball Option Size:NPS 1-6(DN25-150)
V Port Valve Ball

Option Size:NPS0.4

-
